Fiber-to-the-Home Cable Production: How the Manufacturing Process Works
Surprising fact: more than 70% of new U.S. broadband builds now rely on fiber networks that need high-precision manufacturing to hit performance targets.
Shanghai Weiye OFC Equipment manages end-to-end compact fiber unit manufacturing, from choosing brand fibers like Fujikura or Corning SMF-28e to complete test reports that deliver 100% QA.
Our FTTH drop designs are built for aerial, underground, and direct-buried installation, with low-smoke zero-halogen (LSZH), polyvinyl chloride (PVC), and polyethylene (PE) jacket options and configurations from 1–4 cores. We provide OS1/OS2 and OM2–OM4 grades plus G.652D and ITU-T G.657 variants, Pantone-matched sheath colors, and custom logo printing.
Automation and precision equipment stabilize line speed and keep repeatability high. Typical lead times are four to five days for orders < 100 km and seven to ten days for < 500 km, with an min. order of 1 km and free-replacement warranty for quality problems.
Keep reading to learn how materials plus testing and support work together to reduce lifecycle cost and align the product to your network needs.
- Shanghai Weiye OFC Equipment delivers full manufacturing with lab validation for U.S. deployments.
- A range of jacket options and optical grades support varied installation environments.
- Automated lines and machines deliver stable quality and reliable optical performance.
- Quick lead times, low MOQ, and recognized brand fibers help plan procurement reliably.
- Comprehensive test reports and warranty support product reliability and documentation needs.
Expert FTTH manufacturing by Shanghai Weiye OFC Equipment
When schedules and performance count, Shanghai Weiye OFC Equipment delivers customized drop cables with full test documentation.
As a dedicated manufacturer, Shanghai Weiye OFC Equipment combines specialized equipment with stringent material control. We provide customized service and products for residential/MDU deployments. Every order comes with full QA coverage and full test reports.
Our lab conducts high-temperature, salt-fog, and vibration tests to verify durability. Jacket options include LSZH, PVC, and PE. Designs offer flat bow-type and self-supporting styles and use brand fibers such as Fujikura and Corning SMF-28e.
- Documented line control and production checks for fully auditable shipments.
- Technical support for specs, trials, and ramp to volume.
- Modern fixtures and calibration minimize variation so every cable matches operator specs.
How We Produce FTTH Cable
At Shanghai Weiye OFC Equipment, manufacturing steps are built around network requirements, combining brand fiber choices with rigorous test routines.
Fiber Selection & Brand Options
We match fiber draw tower to minimum bend radius, attenuation, and install environment. Options include OS1/OS2 and OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura and Corning SMF-28e are available to satisfy sourcing standards.
Integrating Strength Members
Strength members employ FRP (dielectric) or galvanized steel wire. FRP is ideal where non-conductivity is necessary. Steel wire provides tensile strength for long-span aerial runs and grounding needs.
Extrusion & Process Control
Jacket options include LSZH for indoor flame safety, PVC for flexibility and ease of handling, and PE for UV/moisture resistance outdoors. Tight process control of extruder temperature and capstan speed keeps line speed stable and critical dimensions.
| Component | Dielectric FRP | Metallic Steel |
|---|---|---|
| Primary use | Non-conductive runs | Aerial spans, high tensile |
| Advantage | Lightweight, inert | Very high tensile strength |
| Installation note | Easier terminations | Requires grounding |
Inline and final testing
Inline geometry/concentricity checks run during manufacturing. Final optical tests verify attenuation and reflectance. Each order ships with a 100% test report and lab results from high-temperature, salt fog, and vibration trials to qualify field handling and drop terminations.
Typical lead times are 4–5 days for < 100 km and under 500 km in 7–10 days. Material lot records and FAI approvals provide traceability and compliance for U.S. programs.
FTTH Drop Designs We Build
Shanghai Weiye OFC Equipment offers a focused portfolio of FTTH drop designs that fit indoor risers and long aerial runs. Each option combines tested materials with field-termination geometry and consistent optical performance.
The bow-type flat drop cable keeps a small footprint for risers/ducts. It reduces bend loss for easy routing in MDU corridors and hallways.
Aerial Self-Supporting Options
Self-supporting FTTH drop designs include a messenger element to carry tensile loads. Choose dielectric FRP for electrical isolation or steel wire when bonding and higher tensile strength are required.
Strength member and core layouts
We offer dielectric and metallic strength member configurations to meet safety/EMI requirements. Central loose-tube and flat unitube types balance crush resistance and Fiber draw tower for quick termination.
Indoor/outdoor jackets
Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor UV and moisture resilience. Each family is validated for mechanical and optical quality before shipment.
| Type | Best use | Strength member | Sheath |
|---|---|---|---|
| Flat bow-type | Indoor risers and MDUs | Dielectric FRP | LSZH |
| Self-supporting | Aerial spans | Steel wire or FRP | Polyethylene |
| Central loose-tube | Higher-count builds | FRP | LSZH/PE |
| Unitube flat | Low-count, easy strip | FRP or steel | LSZH/PE |
Production Assets for Speed and Quality
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment reduce manual handling and increase throughput for patch cord prep.
Our production line uses automated machines that cut/strip drop cords to increase output and cut labor variability.
The CLX-BPO2 auto-stripping machine uses PLC + photoelectric control. One cycle is ~1.5 s, giving real-world speeds near 20 terminal operations per minute.
Automated cutting and stripping for drop cable patch cords
The equipment strips LSZH and PVC jackets and trims FRP or steel strength members to precise stub lengths. Pneumatic cylinder actuators deliver fast, repeatable motion and low downtime.
Closed-Loop Control for Repeatability
PLC logic and photoelectric sensors give exact positioning and feedback control. Inline checks feed control charts so operators can correct trends before defects grow.
| Feature | Capability | Result |
|---|---|---|
| Machine | 1.5s cycle, auto-strip | High throughput |
| Actuation | Pneumatic cylinders | High speed and reliability |
| Materials | LSZH & PVC; FRP & steel | Clean, accurate preps |
| Process control | PLC/photoelectric with in-line SPC | Consistent quality, lower rework |
- Auto scrap ejection and ergonomic feeders keep the line clean.
- PCPs document calibration and key parameters.
- Integrated assets and trained operators help meet FTTH volume goals without compromising accuracy.
What the CLX-BPO2 Adds
The CLX-BPO2 provides industrial-grade strip/trim to our line, cutting cycle time while maintaining consistent prep.
Shanghai Weiye OFC Equipment uses the CLX-BPO2 to increase throughput and standardize terminal quality. The unit cycles in ~1.5 seconds, producing around 20 preps per minute in production.
PLC/photoelectric control deliver exact detection and repeatable actuation. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Throughput & Cycle Time
Typical operation speed is ~1.5 seconds per cycle. This translates to steady throughput under continuous line conditions.
Supported Strip and Stub Lengths
The CLX-BPO2 strips LSZH and PVC jackets with an adjustable strip length from 17.5 to 35.0 mm. Reserved strength member stubs are set between 7.0 and 11.0 mm to fit common termination hardware.
Cutting FRP/Steel Members
The machine cleanly cuts FRP and steel wire strength elements while protecting adjacent fibers. Custom tooling are available for nonstandard sizes to maintain precision.
- Auto-eject scrap and sensor-triggered start reduce idle time.
- Small footprint (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg mass simplify cell integration.
- Cylinder-driven motion and closed-loop control boost reliability and lower maintenance interruptions.
| Specification | Rating | Benefit |
|---|---|---|
| Cycle time | ~1.5 s (~20/min) | Supports high-volume runs |
| Jacket strip (A) | 17.5 to 35.0 mm | Compatible with common connectors |
| Reserved stub (B) | 7.0–11.0 mm | Meets strength and termination needs |
| Power & size | 50W @ 110–220V; 40×18×18 cm | Simple integration |
Using this machine, Shanghai Weiye OFC Equipment standardizes prep so field teams get drop parts install-ready. The CLX-BPO2 supports our lines in meeting volume targets without sacrificing quality.
Custom Specs for Your FTTH System
Shanghai Weiye OFC Equipment configures every order to fit your network requirements and simplify field rollout. We combine focused options with predictable schedules so your teams receive ready-to-install products.
Choose 1 to 4 cores with SM or MM fiber. Options include OS1/OS2 plus OM2–OM4 plus G.652D and G.657 variants to align with optics and connector plans.
We match sheath colors to Pantone codes for quick field identification and consistent asset tags.
Jacket materials, print legends, and branding
Select LSZH, PVC, or PE jackets based on route and safety rules. Custom legends/logos support inventory and warranty tracking.
Length options, packaging, and special structures
Standard put-ups are 1 km, 2 km, and 4 km with custom reels and packaging to suit storage and handling. Choose flat bow-type or self-supporting and steel wire or FRP strength members to meet span and isolation needs.
| Choice | Common choice | Benefit |
|---|---|---|
| Length | 1, 2, or 4 km | Less staging, easier reels |
| Sheath | LSZH / PE / PVC | Indoor/Outdoor fit |
| Design | Flat bow / Self-supporting | Flexible routing/span |
As a manufacturer, Shanghai Weiye aligns runs to your schedule and delivers documentation that detail final specs for straightforward QA on site.
Quality assurance, testing, and documentation
Shanghai Weiye OFC Equipment embeds quality checkpoints across the production line so every item ships with recorded acceptance data.
High-temperature, salt spray, and vibration laboratory testing
Our lab runs high-temperature exposure, salt spray corrosion, and mechanical vibration to qualify materials/assemblies. These tests recreate field stresses for indoor and outdoor use.
Per-Reel 100% Reports
Every fiber optic cable includes a 100% test report that records loss, return loss, and key geometry where applicable. Final inspection gates stop nonconforming items before they leave the factory.
Traceability & Compliance
Lot/batch records tie test data to reels and serials so audits and claims are easy to verify. Documentation follows common customer templates to speed approvals and inbound inspection.
- In-line checks plus final inspection prevent field failures and cut warranty events.
- QA packages include specifications confirmation and formatted test data for rapid review.
- Ongoing trend analysis drive preventive maintenance and raise long-term reliability.
| Trial | Why | Result |
|---|---|---|
| Heat exposure | Material stability | Validated heat endurance |
| Salt spray | Corrosion robustness | Qualified for outdoor use |
| Vibration | Mechanical robustness | Improved field reliability |
FTTH Drop Cable Pricing & Cost Drivers
Budgeting for a drop run begins with fiber/jacket selection and is refined by volume and customization.
Typical prices vary widely—from about $30–$1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket chemistry (LSZH, PVC, PE), reel length, and design structure.
Primary Cost Inputs
The primary cost drivers are fiber grade, jacket material, and the chosen structure for deployment.
Self-supporting structures and steel members raise material and labor input. Custom sheath colors/logos/legends add setup and influence price for short runs.
How Volume & Options Affect Cost
Longer reels and higher volume orders lower unit cost. Small quantities often carry setup fees and higher per-unit charges.
- Line changeovers and custom tooling increase lead time and add to cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Framework agreements and indexed pricing stabilize budgets across phases.
| Factor | Effect on price | Recommendation |
|---|---|---|
| Fiber grade | Large | Right-size spec to budget |
| Jacket type | Medium impact | Compare LSZH vs. PE for total cost |
| Order length / volume | High impact | Consolidate where possible |
U.S. Lead Times, MOQ & Delivery
Shanghai Weiye OFC Equipment makes lead times and logistics clear so planners can align crews and sites. Predictable schedules cut downtime and help control cost when a rollout is underway.
Typical production windows and capacity planning
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for < 500 km. We plan capacity to match your rollout milestones and to maintain on-time delivery.
The service team issues production updates and tracking so installation teams know when reels arrive. For tight schedules, we hold contingency capacity to accelerate critical-path orders.
Why MOQ Matters
The MOQ is one kilometer. This reflects line setup such as wire/die adjustments that consume start-up material and scrap.
We review your put-ups and staging to select reels to reduce waste/handling. Staggered batches can balance inventory holding with more frequent small-site deliveries.
Installation readiness and application scenarios
Site conditions dictate whether a self-supporting span, duct pull, or direct-buried run is the right choice for a project.
Deployment Considerations
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with correct strength members to manage sag/tension for long-term reliability.
Duct installations work best with low-friction jackets and crush-resistant builds so pulling does not damage fibers. PE jackets are typical for underground and buried paths where moisture resistance matters.
Direct-buried designs need correct burial depth per local codes and moisture barriers to protect the fiber core long-term.
Indoor Distribution and ONT
Indoor riser and plenum routes prefer LSZH to meet flame and smoke rules. Flat drop profiles strip cleanly and present controlled stubs for quick ONT termination.
We advise on steel vs FRP (dielectric) strength members based on bonding requirements, lightning risk, and hardware fit. Standardized prep from the production line reduces install time and reduces scrap.
| Scenario | Key feature | Field note |
|---|---|---|
| Aerial | Self-supporting (steel/FRP) | Verify messenger hardware/tension |
| Underground duct | Low-friction jacket, crush resistance | Use pull tape + lubricant |
| Direct-buried | PE with moisture barrier | Follow local depth and warning tape rules |
| Indoor | LSZH jacket, tight bend support | Maintain bend radius at wall penetrations |
Our approach ensures a consistent install experience across indoor/outdoor transitions. That leads to fewer callbacks, speeds activations, and reliable field performance for your system.
End-to-end support and after-sales service
Our team coordinates testing, scheduling, and installation guidance to avoid surprises in deployment.
Shanghai Weiye OFC Equipment provides engineering support from early requirements capture through approved drawings and pilot builds. We deliver documentation templates and clear installation notes so field crews work from the same plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full reports and traceability to help QA acceptance.
- Round-the-clock availability for status updates and technical guidance.
- Warranty with free replacement if any quality problems are confirmed.
- Coordination of line schedules for expedites and urgent changes.
- Config control so shipped items match agreed requirements every time.
| Area | What we do | Benefit |
|---|---|---|
| Tech/Eng | Spec review & pre-production builds | Fewer field issues |
| Testing | Lab + 100% reports | Full traceability |
| After-sales | Fast replace + RCA | Minimized downtime |
Conclusion
Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.
We provide custom FTTH drops that pair material choices with validated manufacturing and lab testing. Every reel ships with a 100% test report and documented trials to support U.S. field acceptance.
A hardened production line, including CLX-BPO2-enabled prep machines, reduces variability and shortens turnaround. Our equipment set standardize strip and stub lengths so installers see consistent results at turn-up.
From fiber selection to jacket, printing, and packaging, we balance performance and cost to maximize service life. Dedicated support covers scheduling/logistics/after-sales so your deployment stays on plan.
Contact Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every fiber optic and optic cable shipment with laboratory validation and responsive service.
